TTL Trigger Box
Precision TTL signal trigger hardware with BNC connectors and USB-C connectivity. Built for timing-critical applications where synchronization between systems is essential.
InterfaceUSB-C
ConnectionsBNC In / Out
Version1.0
Overview
| Category | Signal Timing / Test Equipment |
| Use Case | Serial trigger box with TTL-level signals |
Technical Specifications
| SIGNAL STANDARD | TTL (Transistor-Transistor Logic) — 0V / 5V logic levels |
| I/O | TTL Input + TTL Output |
| HOST INTERFACE | USB-C (Serial) |
| Serial over USB-C | Serial over USB-C |
| POWER | Bus-powered via USB-C |
Features
TTL In and Out via BNC connectors for precise signal routing
USB-C host interface — connects to any modern PC or Mac
Acts as a serial trigger box for timing-sensitive test setups
Enables synchronization between multiple systems or instruments
Tested and verified with Quincy software
Custom built to order — specify your exact requirements
Use Cases
- Timing synchronization between lab instruments
- Triggering cameras, DAQ systems, or test equipment via TTL
- Serial trigger control from a PC application
- Any application requiring precise TTL-level event timing
